Additional Notes
6' Diameter
Final Materials Due by November 17, 2023.
Banner material wrap under the fire strobes and above the fire extinguishers on the column 8’ tall.
The top of the extinguisher box to the floor is 4ft.
From the top of the box to the strobe is 12 ft.
Obstructions: No portion of the fire alarm, fire extinguishers, AED boxes, fire hose cabinets, sidewalks, entries, passageways, corridors, doors, aisles, elevators, vestibules, ventilators, light fixtures, or access ways to onsite public utilities shall be obstructed, or caused to be obstructed, or caused to be used for any purpose other than ingress or egress. All storage shall be maintained 18 inches or more below sprinkler head deflectors. A minimum three (3) foot clearance shall be provided around all fire extinguishers, fire hose cabinets, standpipe connections, automatic external defibrillators. These devices shall also be clearly accessible and visible from the aisles. NOTE: If fire extinguishers are obstructed, the client is responsible for providing a fully operational 2A-10BC fire extinguisher in a visible, accessible location; subject to approval by Fire Marshal.
